Features

 Low Clamping Voltage

 Small Body Outline Dimensions: 0.047 x 0.032 (1.20 mm x 0.80 mm)

 Low Body Height: 0.028 (0.7 mm)

 Stand−off Voltage: 2.5 V − 12 V

 Peak Power up to 240 Watts @ 8 x 20 s Pulse

 Low Leakage

 Response Time is Typically < 1 ns

 ESD Rating of Class 3 (> 16 kV) per Human Body Model

 IEC61000−4−2 Level 4 ESD Protection

 IEC61000−4−4 Level 4 EFT Protection

 SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable

 These Devices are Pb−Free and are RoHS Compliant

Applications

1. High-Speed Data Interface Protection:

This is its primary application. Its ultra-low capacitance and sub-nanosecond response time ensure signal integrity is not compromised, making it perfect for:

• USB 2.0 / 3.0 data lines

• HDMI and DisplayPort interfaces

• High-speed Ethernet RJ45 ports

• Mobile High-Definition Link (MHL) and SATA interfaces

2. Portable Electronic Devices:
Its miniature SOD-523 package is ideal for space-constrained devices, providing robust ESD protection for ports in:

• Smartphones and tablets (charging/data ports, audio jacks)

• Laptops and ultrabooks

• Wearable devices (smartwatches, fitness trackers)

• Digital cameras and portable gaming consoles

3. Communication & Computing Equipment:

• High-speed data lines in servers, routers, and switches.

• Cellular RF antennas (e.g., for GPS, Wi-Fi, Bluetooth modules), where its 3.3V working voltage matches the circuit voltage.

Description

The ESD5Z Series is designed to protect voltage sensitive components from ESD and transient voltage events. Excellent clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium. Because of its small size, it is suited for use in cellular phones, portable devices, digital cameras, power supplies and many other portable applications.
