NLAS2750MUTAG Low On-Resistance (0.6Ω) High-Speed Switching 1.8V-5.5V Wide Voltage ESD Protection Tiny SOT-23 Package RoHS Compliant Ideal for Portable & IoT Devices
Features
• Capable to Switch Negative Swing Audio Signals Without Requiring a DC Blocking Capacitor
• Low On−resistance (RON)
• Low Voltage Digital Control Logic: (VINH = 1.4 V @ VCC = 2.7 V to 4.3 V)
• Low Power Consumption (ICC ≤ 250 nA)
• Space Saving 1.4 mm x 1.8 mm Package UQFN Package
• This is a Pb−Free Device
Typical Applications
• Cellular Phones
• Portable Media Players
Description
The NLAS2750MUTAG is a high-efficiency, low-voltage single-pole double-throw (SPDT)analog switch designed for portable devices, loT applications, and signal routing systems.With an ultra-low on-resistance (0.62 typical) and minimal power consumption, this switchensures high signal integrity while reducing voltage drop and distortion.
Key Features & Benefits
1. Ultra-Low On-Resistance (0.62)- Minimizes signal loss and power dissipation, making itideal for precision analog and digital switching.
2. Wide Voltage Range (1.8V to 5.5v)- Supports multiple logic levels, ensuring compatibilitywith battery-powered devices (Li-ion, 3.3V/5V systems).
3. High-speed switching (Fast Turn-On/Off)- Enables quick signal routing for dataacquisition, audio switching, and multiplexing applications.
4. Robust ESD Protection (±8kV HBM) - Enhances reliability in harsh environments, protectingsensitive circuits from electrostatic discharge.
Compact SOT-23 Package - Saves board space in wearables, smartphones, and loT sensors5.
while allowing easy PCB integration.
6. Low Power Consumption (Near-Zero Leakage Current)- Extends battery life in portableelectronics.
7. RoHS Compliant & Lead-Free- Meets global environmental standards for safemanufacturing and disposal.
INFORMATION
|
Category
|
|
|
|
Manufacturer
|
onsemi
|
|
|
Series
|
-
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Obsolete
|
|
|
Switch Circuit
|
SPDT
|
|
|
Multiplexer/Demultiplexer Circuit
|
2:1
|
|
|
Number of Circuits
|
2
|
|
|
On-State Resistance (Max)
|
1.3Ohm
|
|
|
Channel-to-Channel Matching (ΔRon)
|
100mOhm
|
|
|
Voltage - Supply, Single (V+)
|
1.8V ~ 5V
|
|
|
Voltage - Supply, Dual (V±)
|
-
|
|
|
Switch Time (Ton, Toff) (Max)
|
150ns, 130ns
|
|
|
-3db Bandwidth
|
44MHz
|
|
|
Charge Injection
|
60pC
|
|
|
Channel Capacitance (CS(off), CD(off))
|
5pF
|
|
|
Current - Leakage (IS(off)) (Max)
|
250nA
|
|
|
Crosstalk
|
-60dB @ 300kHz
|
|
|
Operating Temperature
|
-40°C ~ 85°C (TA)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
10-UFQFN
|
|
|
Supplier Device Package
|
10-UQFN (1.4x1.8)
|
|
|
Base Product Number
|
Drawing
