CDBC560-G 560Ω@100MHz Common Mode Choke High Current Rating Wide Temp Range Low DCR Excellent EMI Suppression RoHS Compliant Compact Design Power & Data Line Protection

CDBC560-G 560Ω@100MHz Common Mode Choke High Current Rating Wide Temp Range Low DCR Excellent EMI Suppression RoHS Compliant Compact Design Power & Data Line Protection

Features

Ideal for surface mount applications

Easy pick and place

Plastic package has Underwriters Lab.

flammability classification 94V-0
Built-in strain relief
Low forward voltage drop

Applications

Switching Mode Power Supplies (SMPS)

Suppresses high-frequency common mode noise at power input/output terminals, improving power purity and stability.

Data Communication Equipment

Used in data lines such as Ethernet, USB, and CAN bus to reduce common mode interference during signal transmission and enhance data integrity.

Industrial Automation Systems

Filters electromagnetic interference in motor drives, PLC controllers, and other industrial equipment, improving system noise immunity and reliability.

Consumer Electronics

Applied in products like TVs, routers, and adapters to comply with EMC regulations (e.g., FCC and CE standards).

New Energy Vehicles and Charging Infrastructure

Used in onboard chargers (OBC), battery management systems (BMS), and charging stations for noise suppression in power and communication lines.

Medical Equipment

Provides EMI filtering for power and signal lines in precision medical instruments (e.g., monitors and diagnostic devices), ensuring safe operation.

Description

High-frequency noise suppression (560Ω @ 100MHz impedance)

High current rating: Supports high-current circuit design.

Low DC resistance (DCR): Reduces power loss and heat generation.

Wide temperature range: Suitable for harsh environments such as industrial and automotive electronics.

Compact design: Saves PCB space and supports high-density integration.

RoHS compliance: Meets environmental regulatory requirements.

INFORMATION

Drawing

Our advantage :

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

be sure to meet your need for all kinds of components. ^_^
